FPV Drone Frame
Created with Pixso. Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories

MOQ: 5 pieces
Price: CN¥91.43/pieces 5-99 pieces
Detail Information
Brand Name:
Padi Flight/OEM
Compatible Brand:
For Fpv
Private Mold:
Yes
Place Of Origin:
Guangdong, China
Material:
Carbon Fiber, Carbon Fiber
Product Name:
5 Inch Drone Rack
Rack Type:
H Type
Maximum Supporting Blades:
5 Inches
Wheelbase:
225mm
Weight:
102g
Dimensions:
145*172mm
Base Plate Thickness:
2.5mm
Thickness Of The Splint:
2mm
Arm Thickness:
5mm
Highlight:

Carbon Fiber FPV Drone Frame

,

Padi Flight Mark 4 FPV Frame

,

5-Inch FPV Drone Frame

Product Description
Product Description

Padi Flight Mak 4 FPV drone rack, lighter rack with better performance and more convenient installation,Smooth flight, FPV shooting easier and more elegant.

H-shaped structure, does not affect the flight experience.

Instead, compared to the X-shaped structure, the arm is shorter and lighter. At the same time, the strength of the arm is higher.

H-type layout, the middle section of the cabin installation space more, the center of gravity is lower, the flight is more stable.

FPV lens mounting size of 19mm width, suitable for miniature lenses, such as micro eagle micro slingshot and so on.

At the same time, the cabin is reserved for 30.5*30.5 and 20*20 two kinds of hole spacing of the flight control installation position. Suitable for a variety of flight control equipment installation.

The arm has been chamfered and polished, with fine workmanship and reasonable structure.





Product specifications:

Rack type: H type

Maximum support blade: 5 inch

Wheelbase: 225mm

Weight: 102g

Size * 145*172mm

Bottom plate thickness: 2.5mm

Top plate thickness: 2.5mm

Side plate thickness: 2.5mm

Splint thickness: 2mm

Front and rear protective frame plate thickness: 2.5mm

Arm thickness: 5mm



Recommend Configuration: (Welcome to contact sales for recommendations of other accessories)

Flight Control: F3/F4/F7/H743
Motor: 2205/2206/2207/2305/2306
Electric: 30A-60A
Battery: 4S 1500mAh ~ 6S 1400mAh

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 0

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 1

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 2

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 3

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 4

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 5

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 6

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 7

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 8

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 9

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 10



Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 11

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 12

Packaging & Shipping

Please contact our sales professionals for export details on UAV packaging

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 13



Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 14

Company Information

Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 15



Padi Flight Technology Co., Ltd is a professional drone equipment manufacturing factory, located in Shenzhen, China. With over 1000 square meters of plant space, we have 15 years of experience in this industry.

We specialize in the design, development, and distribution of FPV drones along with a comprehensive range of UAV accessories. We have positioned ourselves as a leading player in the FPV drone market, known for our innovation, quality, and commitment to enhancing the user experience.



We also provide the industry's professional OEM and ODM technology and services.



Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 16Padi Flight Mark 4 5-Inch 225 mm Carbon Fiber FPV Frame for Remote Control FPV Drone Accessories 17



FAQ

Q:Why choose Padi Flight?

A:1.Highly professional team, rich industry experience, perfect management system and stable production capacity.

   2.Provide a small MOQ for you to check the quality, as well as excellent after-sales service.

   3.Professional sales staff provide quality service and patient buying guidance to give you a comfortable buying experience.

   4.We provide one-stop service and support OEM/ODM.





Q:How can we guarantee quality?

A:1.Always a pre-production sample before mass production;

2.Always final Inspection before shipment;

3.Professional sales staff will communicate with you to confirm every link



Q:What's the lead time?

A:Sample needs 3-7 days, mass production needs 7-10 days, according to your order requirements & volumes.



Q:How to place an order from you?

A:Please send the products you like to us and our professional sales will contact with you within 24 hours to confirm the details of the products and negotiate. After you confirm the order, we will guide you through payment and arrange delivery, tell you the tracking number and help track the logistics.

 We look forward to your comments on our products and services.
