products details

Home Products

Anti Drone Drone Anti Alarm Systems Amplifier Module Lora Module

Brand Name:	ODM or OEM
MOQ:	1 piece
Price:	Negotiable
Payment Terms:	T/T, PayPal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Model NO.:

PF-AF27Y

Support Network:

GSM

Information Content:

Data

Condition:

New

Function:

Anti Fpv Module

Frequency:

700-1000MHz

Power:

40W

Operating Voltage:

24-28V

Current:

3000mA±500

RF Interface:

SMA

RF Interface Impedance:

50Ω

Packing Size:

140*54*20mm

Temperature:

-40ºC+80ºC

Material:

Aluminum

Single Package Size:

15.5X6X3 Cm

Single Gross Weight:

0.250 Kg

Transport Package:

Carton

Specification:

38*112*19.5mm

Trademark:

Origin:

China

Product Description

Specification

About this productIncludes generated contents
High Power and Frequency Range: This anti FPV digital modulation power amplifier module operates within a wide frequency range of 700-1000 MHz, ensuring reliable communication in various environments.
Robust Construction: Made from durable aluminum, this module is built to withstand harsh conditions, with a temperature range of -40°C to +80°C.
High Power Output: With a power output of 40W, this module is ideal for applications requiring strong signal transmission.
Wide Operating Voltage: The module can operate within a wide voltage range of 24-28V, accommodating various power supply requirements.
User-friendly Interface: The SMA RF interface with 50 ohm impedance makes it easy to integrate with other devices, providing a seamless user experience for users like you.

Product Overview

Place of Origin

Guangdong, China

Name

Anti FPV Module

Frequency

700-1000mhz

Power

40W

Operating Voltage

24-28V

Current

3000mA±500

RF interface

SMA

RF interface impedance

50Ω

Size

140*54*20mm

Temperature

-40ºC+80ºC

Material

Aluminum

Test Item		indicator	Remark
Frequency Range		700-1000mhz	Built-in interference source
Working Voltage		28V	24-28V
Max Output Power		47dBm	1.5G 50W
Working Efficiency		≥60%
Gain		47dbi	peak-to-peak value
Passband Riplpe		≤2dB	peak-to-peak value
High-Low Temperature Test	Working Temperature(ºC)	-10~+55ºC	It can start at low temperatures
	Gain Stability	±1.5 @-40ºC~+55ºC
	Power Stability	±1.5 @-40ºC~+55ºC
Power supply requirements		≥3.7A	Continuous wave output 50W
Power supply interface			Red + and black -
Enable			White line high level on, low level off
RF Connector		SMA	SMA external screw base
Size		37.311219.5mm	Excluding SMA
Weight		160g

FAQ
1.Question : Why choose us ?
Answer : We have 6 years experience on drone business and one stop solutions of drone , especially on security .

2.Question : What is the minimum order quantity(MOQ) ?
Answer : No quantity limited , sample order or small order is acceptable.

3.Question : Could you offer wholesale price ?
Answer : Supportive,and wholesale price is better.

4.Question : How long is your delivery time ?
Answer : Generally 1-3 working days if stock available . Or need extra 3 working days to prepare goods .

5.Question : What is your product quality ?
Answer : Our raw materials purchased from qualified suppliers . And we have very strict qc standard to assure our final products meet your requirements .

6.Question : Can you print my own logo on the products ?
Answer : Yes , logo,packing design and other oem services are available .
We will prepare artwork for visual confirmation , then sample confirm finally bulk production .

7.Question : What's the payment terms ?
Answer : T/T , Western union , Paypal , Alipay and so on.
